Feature
■ Use with soil moisture/EC/temperature or many other sensor
■ Data can be read out/saved manually or automatically
■ Utility software for data download/export through WiFi
■ Internal realtime clock
■ Battery-powered for field application
■ Auxiliary power input through USB Type-C
Applications
■ Industrial Monitoring
■ Environment Monitoring
■ Scientific Research
■ Agriculture
■ Horticulture
| Specification | |
| Sensor Input | 1 Channel Sensor Input |
| Power Supply | Two options when ordering, both support USB type C (5V DC) auxiliary power input
■ 3*AA Battery ■ 3.7V Chargeable lithium battery |
| Data Readout and Save | Manually/Automatically |
| Data Storage and Export | Two options when ordering,Data can be download through WiFi
■ 256 Items Storage ■ 100,000 Items Storage |
| Realtime Clock | Supported |
| Display | 160*128 Color LCD |
| Operation | -10~50℃ |
| IP Rating | IP20 NEMA1 |
| Dimensions | 170*80*40mm |
| Supported Sensors | Soil Moisture/Temperature sensor
Soil Moisture/EC/Temperature sensor Soil Moisture/EC/Temperature/NPK sensor Substrate Moisture/EC/Temperature sensor Rugged Temperature sensor Air Temperature/Humidity/Dew sensor Air Temperature/Humidity/Dew/Barometric sensor Air Temperature/Humidity/Dew/Barometric/Vapor Pressure sensor Ambient Light sensor Solar Radiation sensor Leaf Wetness sensor |
