IPX1 and IPX2 testing are part of the Ingress Protection (IP) code, which classifies and rates the degree of protection provided against the intrusion of solid objects and water into electrical enclosures and mechanical casings. The IP code is internationally recognized and defined in the IEC 60529 standard.
These tests are commonly applied to products such as outdoor electrical equipment, luminaires, and enclosures that need to demonstrate a degree of protection against water ingress according to international standards and regulations.
Product Introduction
Wall-mounted IPX1 IPX2 test equipment is a cost-saving and spac-saving option for those who want to puchase more affordable equipment to conduct the waterproof testing for their products.
Appliance
IPX1 and IPX2 testing are part of the Ingress Protection (IP) code, which classifies and rates the degree of protection provided against the intrusion of solid objects and water into electrical enclosures and mechanical casings. The IP code is internationally recognized and defined in the IEC 60529 standard.
These tests are commonly applied to products such as outdoor electrical equipment, luminaires, and enclosures that need to demonstrate a degree of protection against water ingress according to international standards and regulations.
Technology parameter:
| No. | model | HNT-IP12T-800 | HNT-IP12T-1000 | HNT-IP12T-1200 |
| 1 | Drop of rain area | 800*800mm (can customize) | 1000*1000mm (can customize) | 1200*1200mm (can customize) |
| 2 | Equipment outer dimensions | L1000*D1000*H2500mm | L1200*D1200*H2500mm | L1450*D1450*H2600mm |
| 3 | Turntable diameter | ￠500 mm | ￠600 mm | ￠600 mm |
| 4 | Dripping aperture | ￠0.4mm | ||
| 5 | The distance between holes | 20*20 mm | ||
| 6 | Rainfall | 1-5mm/Min(±0.5mm/min) | ||
| 7 | Flow adjustment mode | manual setting | ||
| 8 | Drop of rain tank lifting height | 1000*1800 adjustable | ||
| 9 | Turntable bearing | 50KG | ||
| 10 | Turntable Speed | 1 r/min | ||
| 11 | Turntable Adjustable Incline | 0° or 15° | ||
| 12 | Turntable lifting range | Fixed | ||
| 13 | Testing time | 0-999 min | ||
| 14 | Protective device | Leakage, water shortage, short circuit | ||
| 15 | Power (V) | 220V | ||
| 16 | Power (KW) | 1 | ||
| 17 | Standards compliant | IEC60529（IPX1 IPX2) | ||
